floor shot blaster

Epoxy floor cleaning machine

Author:Shot Blasting Machine Date:2017/4/15 10:34:45 Page View:

Specification

LM-270

shot blasting cleaning range 270mm

LM-350

shot blasting cleaning range 350mm

LM-550

shot blasting cleaning range 550mm

LM-850

shot blasting cleaning range 850mm


Product Images

Epoxy floor cleaning machine
Epoxy floor cleaning machine
Epoxy floor cleaning machine
Epoxy floor cleaning machine
Epoxy floor cleaning machine



Work Introduction

Epoxy Flooring Cleaning Shot Blasting Machine is a specialized equipment for surface treatment of epoxy flooring. It applies the shot blasting principle of fixed shot blasting machines to mobile shot blasting machines. The mobile power equipment drives the machine to move automatically and perform shot blasting on the ground. The following is a detailed introduction to the Epoxy Flooring Cleaning Shot Blasting Machine:

I. Working Principle
The epoxy flooring shot blasting machine utilizes a motor-driven shot blasting impeller that generates centrifugal force and wind during high-speed rotation. It projects shot blasting media such as steel shots onto the surface of the flooring at high speed, impacting and rolling over the surface to remove various contaminants, stains, old paint, oil stains, and outdated colors, achieving the effects of cleaning and roughening. At the same time, the dust removal system equipped with the machine can effectively collect dust and impurities generated during the process, enabling pollution-free construction.

II. Characteristics and Advantages
Efficient Cleaning: The epoxy flooring shot blasting machine can efficiently remove various contaminants and stains from the surface of the flooring, improving cleaning efficiency.
Enhanced Adhesion: After shot blasting treatment, the surface of the flooring becomes rough and uniform, significantly increasing the adhesion area and adhesion of materials such as waterproof layers and epoxy flooring paint.
Environmental Protection and Energy Saving: The dust removal system equipped with the machine can effectively reduce dust pollution during construction, and the shot blasting media can be reused, lowering construction costs.
Wide Range of Applications: The epoxy flooring shot blasting machine is not only suitable for cleaning and roughening epoxy flooring but also can be used for removing laitance from concrete surfaces, bridge waterproofing and anti-corrosion treatment, rust removal from steel surfaces, and various other occasions.
Easy Operation: The machine adopts an automated design, making it easy to operate and significantly reducing the labor intensity of construction personnel.

III. Application Scenarios
The epoxy flooring shot blasting machine is widely used in the following scenarios:

Epoxy Flooring Construction: Before applying epoxy flooring paint, use the epoxy flooring shot blasting machine to clean and roughen the surface of the flooring, enhancing the adhesion and wear resistance of the flooring paint.
Bridge Waterproofing and Anti-corrosion: Perform shot blasting treatment on the surface of bridges to remove contaminants such as dust, rust, and oil stains, improving the adhesion and durability of waterproof and anti-corrosion coatings.
Rust Removal from Steel Surfaces: Perform rust removal and roughening treatment on steel surfaces to meet the pretreatment requirements for anti-corrosion coatings or heavy anti-corrosion coatings.
Asphalt Pavement Maintenance: Perform roughening treatment on asphalt pavement to improve its anti-skid performance and durability.

Composition Table of S230 Cast Steel Shot


Modle

LM-270

LM-350

LM-550

LM-850

diameter of shot blasting wheel(mm)

200

200

200

200

Working width (mm)

270

350

550

850

Concrete surface cleaning efficiency

80/h

100/h

400/h

600/h

steel plate cleaning efficiency

15-20/h

20-25/h

75-100/h

100-160/h

Dust removal pipe diameter (mm)

120mm

120mm

150mm

150mm

Steel shot size

1.2-1.5mm

1.2-1.5mm

1.5-1.8mm

1.5-1.8mm

Consumption of steel shot

10g/

10g/

10g/

10g/

Motor power (kw)

11KW

11KW

11KW*2

15KW*2

Weight (kg)

320KG

350KG

570KG

700KG

Walking speed

0.5~20m/min

Forward,backward

0.5~20m/min

Forward,backward

0.5~20m/min

Forward,backward

0.5~20m/min

Forward,backward


FAQ

Epoxy floor cleaning machine
Q1. What is your terms of packing?
    Generally, we pack our goods in nPacked in wooden cases。
Q2. What is your terms of payment?
    30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
     FOB
Q4. How about your delivery time?
    Generally, it will take 15 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5.  Do you test all your goods before delivery?
    Yes, we have 100% test before delivery
Q6:  How do you make our business long-term and good relationship?
    1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
